Intel Core i9-12900F Desktop Processor - Retail

Intel Core i9 Core 12900F Desktop Processor 30M Cache, up to 5.10 GHz

Essentials

12th Generation Intel Core i9 Processors

Code Name
Products formerly Alder Lake

Vertical Segment
Desktop

Processor Number
i9-12900F

Lithography
Intel 7

Use Conditions
PC/Client/Tablet

CPU Specifications

Number of Performance-cores
8

Number of Efficient-cores
8

Total Threads
24

Max Turbo Frequency
5.10 GHz

Intel Turbo Boost Max Technology 3.0 Frequency
5.10 GHz

Performance-core Max Turbo Frequency
5.00 GHz

Efficient-core Max Turbo Frequency
3.80 GHz

Performance-core Base Frequency
2.40 GHz

Efficient-core Base Frequency
1.80 GHz

Cache
30 MB Intel Smart Cache

Total L2 Cache
14 MB

Processor Base Power
65 W

Maximum Turbo Power
202 W

Supplemental Information

Max Memory Size (dependent on memory type)
128 GB

Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s

Max Number of Memory Channels
2

Max Memory Bandwidth
76.8 GB/s

Expansion Options
Direct Media Interface (DMI) Revision
4.0

Max Number of DMI Lanes
8
Scalability
1S Only

PCI Express Revision
5.0 and 4.0

PCI Express Configurations
Up to 1x16+4, 2x8+4

Max Number of PCI Express Lanes
20

Package Specifications
Sockets Supported
FCLGA1700

Max CPU Configuration
1

Thermal Solution Specification
PCG 2020C

TJUNCTION
100^oC

Package Size
45.0 mm x 37.5 mm

Advanced Technologies
Intel Gaussian and Neural Accelerator
3.0

Intel Thread Director
Yes

Intel Deep Learning Boost (Intel DL Boost)
Yes

Intel Optane Memory Supported
Yes

Intel Speed Shift Technology
Yes

Intel Turbo Boost Max Technology 3.0
Yes

Intel Turbo Boost Technology
2.0

Intel Hyper-Threading Technology
Yes

Intel 64
Yes

Instruction Set
64-bit

Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2

Idle States
Yes

Enhanced Intel SpeedStep Technology
Yes

Thermal Monitoring Technologies
Yes

Intel Volume Management Device (VMD)
Yes

Security and Reliability
Intel Standard Manageability (ISM)
Yes

Intel AES New Instructions
Yes

Secure Key
Yes

Intel OS Guard
Yes

Execute Disable Bit
Yes

Intel Boot Guard
Yes

Mode-based Execute Control (MBEC)
Yes

Intel Control-Flow Enforcement Technology
Yes

Intel Virtualization Technology (VT-x)
Yes

Intel Virtualization Technology for Directed I/O (VT-d)
Yes

Intel VT-x with Extended Page Tables (EPT)
Yes

Item Dimension (L"xW"xH")
6 x 5 x 5

Weight
2 lbs

Warranty Information
3-year limited
