Intel CPU BX8071512700 Corei7-12700 BOX ADL 12Cores/20Thread 2.1GHz 25M S1700 Retail

Essentials
Product Collection
12th Generation Intel Core i7 Processors
Code Name
Products formerly Alder Lake
Vertical Segment
Desktop
Processor Number
i7-12700
Lithography
Intel 7
Use Conditions
PC/Client/Tablet, Workstation
CPU Specifications
Total Cores
12
Number of Performance-cores
8
Number of Efficient-cores
4
Total Threads
20
Max Turbo Frequency
4.90 GHz
Intel Turbo Boost Max Technology 3.0 Frequency
4.90 GHz
Performance-core Max Turbo Frequency
4.80 GHz
Efficient-core Max Turbo Frequency
3.60 GHz
Performance-core Base Frequency
2.10 GHz
Efficient-core Base Frequency
1.60 GHz
Cache
25 MB Intel Smart Cache
Total L2 Cache
12 MB
Processor Base Power
65 W
Maximum Turbo Power
180 W
Supplemental Information
Embedded Options Available
Yes
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max Number of Memory Channels
2
Max Memory Bandwidth
76.8 GB/s
ECC Memory Supported
Yes
Processor Graphics
Processor Graphics
Intel UHD Graphics 770
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.50 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units
32
Max Resolution (HDMI)
4096 x 2160 at 60Hz
Max Resolution (DP)
7680 x 4320 at 60Hz
Max Resolution (eDP - Integrated Flat Panel)
5120 x 3200 at 120Hz
DirectX Support
12
OpenGL Support
4.5
Multi-Format Codec Engines
2
Intel Quick Sync Video
Yes
Intel Clear Video HD Technology
Yes
Number of Displays Supported
4
Device ID
0x4680
OpenCL Support
2.1
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max Number of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations
Up to 1x16+4, 2x8+4
Max Number of PCI Express Lanes
20
Package Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020C
TJUNCTION
100^oC
Package Size
45.0 mm x 37.5 mm
Advanced Technologies
Intel Gaussian and Neural Accelerator
3.0
Intel Thread Director
Yes
Intel Deep Learning Boost (Intel DL Boost)
Yes
Intel Optane Memory Supported
Yes
Intel Speed Shift Technology
Yes
Intel Turbo Boost Max Technology 3.0
Yes
Intel Turbo Boost Technology
2.0
Intel Hyper-Threading Technology
Yes
Intel 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States
Yes
Enhanced Intel SpeedStep Technology
Yes
Thermal Monitoring Technologies
Yes
Intel Volume Management Device (VMD)
Yes
Security and Reliability
Intel vPro Platform Eligibility
Yes
Intel vPro Enterprise Platform Eligibility
Yes
Intel vPro Essentials Platform Eligibility
Yes
Intel Threat Detection Technology (TDT)
Yes
Intel Active Management Technology (AMT)
Yes
Intel Standard Manageability (ISM)
Yes
Intel One-Click Recovery
Yes
Intel Hardware Shield Eligibility
Yes
Intel AES New Instructions
Yes
Secure Key
Yes
Intel OS Guard
Yes
Intel Trusted Execution Technology
Yes
Execute Disable Bit
Yes
Intel Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel Control-Flow Enforcement Technology
Yes
Intel Total Memory Encryption - Multi Key
Yes
Intel Total Memory Encryption
Yes
Intel Stable IT Platform Program (SIPP)
Yes
Intel Virtualization Technology with Redirect Protection (VT-rp)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Item Dimension (L"xW"xH")
5 x 3 x 4

Weight
1 lb

Warranty Information
3-year limited
