MSI PRO X670-P WIFI Desktop Motherboard
PRO X670-P WIFI Motherboard supports AMD Ryzen 7000 Series Desktop Processors and DDR5 Memory. It has an enhanced power design with 14+2+1 duet Rail Power System, dual 8-pin CPU power connectors, Core Boost and Memory Boost. Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and Double-sided M.2 Shield Frozr are built for high performance system and non-stop gaming as part of the Premium Thermal Solution. High Quality 8-layer PCB is made with 2oz thickened copper and server grade level material. Lightning fast gaming experience is possible with PCIe 4.0 slots, Lightning Gen 5 x4 M.2, USB 3.2 Gen 2x2. 2.5G LAN and Wi-Fi 6E Solution offers upgraded network solution for professional and multimedia use, and delivers a secure, stable and fast network connection. Reward your ears with studio grade sound quality for the most immersive gaming experience with Audio Boost 5.
General Information
Manufacturer: MSI
Manufacturer Part Number: X670PROPWIFI
Brand Name: MSI
Product Series: PRO
Product Model: PRO X670-P WIFI
Product Name: PRO X670-P WIFI Desktop Motherboard
Product Type: Desktop Motherboard
Processor & Chipset
Chipset Manufacturer: AMD
Chipset Model: X670
Total Processor Supported: 1
Processor Socket: Socket AM5
Processor Supported: Ryzen
Memory
Number of Memory Slots: 4
Maximum Memory Supported: 128 GB
Memory Technology: DDR5 SDRAM
I/O Controller
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0
RAID Levels: 1
RAID Levels: 10
Video
Onboard Video: CPU Dependent Video
Audio
Audio Channels: 7.1
Network & Communication
Bluetooth: Yes
2.5Gigabit Ethernet: Yes
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax
I/O Expansions
Number of Total Expansion Slots: 4
Total Number of PCI Express Slots: 4
Number of PCI Express x1 Slots: 1
Number of PCI Express x16 Slots: 4
Interfaces/Ports
Total Number of USB Ports: 8
Number of USB 3.2 Ports: 2
Number of USB 3.2 Gen 1 Ports: 4
Number of USB 3.2 Gen 2 Type-A Ports: 2
S/PDIF: Yes
HDMI: Yes
DisplayPort: Yes
Number of Network (RJ-45) Ports: 1
Onboard Interfaces
Number of SATA Interfaces: 6
Number of M.2 Interfaces: 4
Total Number of Onboard USB Ports: 9
Number of Onboard USB 2.0 Ports: 4
Number of Onboard USB 3.2 Ports: 5
Physical Characteristics
Form Factor: ATX
Width: 12"
Depth: 9.6"
Miscellaneous
Brand Compatibility: AMD
Country of Origin: China
Warranty
Limited Warranty: 3 Year
