MSI

MSI MPG X570S CARBON EK X ATX Desktop Motherboard

MSI MPG X570S CARBON EK X ATX Desktop Motherboard

Regular price $604.99 USD
Regular price Sale price $604.99 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

MSI MPG X570S CARBON EK X Desktop Motherboard

EK CUSTOM-DESIGNED CPU + VRM WATER COOLING
Sustain the high performing for AMD Ryzen 5000 series processors, a custom-designed EK cooling solution that offers pristine cooling for both the CPU and VRM power delivery section is used to prevent thermal throttling, allowing gamers to sustain heavy gaming loadings without the noisy environment. It's ready for everything!

ENHANCED PERFORMANCE
High performance MSI motherboards are loaded with advanced features and the latest technology to overwhelm any challenge at hand no matter whether you’re a gamer, prosumer, or PC enthusiast.

A HUGE STEP OF DDR PERFORMANCE
MSI OC LAB does not merely work hard on extreme overclocking. The A-XMP memory profile has great improvement on performance and efficiency for X570. Easy to enable A-XMP profile with auto power settings to get the best memory speed and stability.

HIGH-BANDWIDTH AND LOW-LATENCY NETWORK
2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.

- Supports AMD Ryzen 5000 series, 5000 G-series, 4000 G-series, 3000 series, 3000 G-series, 2000 series and 2000 G-series desktop processors

- Supports DDR4 Memory, up to 5300+(OC) MHz

- CPU + VRM Water Cooling: A custom-designed EK monoblock with build-in inflow indicator that offers pristine cooling for both the CPU and VRM power delivery section

- Enhanced Power Design: 14+2 Duet Rail Power System, 8-pin plus 4-pin CPU power connectors, Core Boost, DDR4 Boost

- Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2

- M.2 Shield Frozr: All M.2 slots covered with Shield Frozr to built for high performance system and non-stop gaming experience

- MYSTIC LIGHT: 16.8 million colors / 29 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip.

- 2.5G LAN with LAN Manager and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection

- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience

- High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material

- Pre-installed I/O Shield: Better EMI protection and more convenience for installation

General Information
Manufacturer:   MSI
Manufacturer Part Number:   X570SCAREKX
Brand Name:   MSI
Product Line:   MPG
Product Model:   X570S CARBON EK X
Product Name:   MPG X570S CARBON EK X Desktop Motherboard
Product Type:   Desktop Motherboard

Processor & Chipset
Chipset Manufacturer:   AMD
Chipset Model:   X570
Total Processor Supported:   1
Processor Socket:   Socket AM4
Processor Supported:   Ryzen 3 PRO
Processor Supported:   Ryzen 5 Pro
Processor Supported:   Ryzen 7
Processor Supported:   Ryzen 9
Processor Supported:   Ryzen 3
Processor Supported:   Ryzen 5
Processor Supported:   Ryzen 7 PRO
Multi GPU Supported:   CrossFire

Memory
Number of Memory Slots:   4
Memory Form Factor:   DIMM
Memory Form Factor:   UDIMM
Maximum Memory Supported:   128 GB
Memory Technology:   DDR4 SDRAM
Memory Speed Supported:   1866 MHz
Memory Speed Supported:   2400 MHz
Memory Speed Supported:   2667 MHz
Memory Speed Supported:   2933 MHz
Memory Speed Supported:   3000 MHz
Memory Speed Supported:   3200 MHz
Memory Speed Supported:   4000 MHz
Memory Speed Supported:   4266 MHz
Memory Speed Supported:   5300 MHz
Memory Speed Supported:   2133 MHz
Memory Speed Supported:   2800 MHz
Memory Speed Supported:   3066 MHz
Memory Speed Supported:   3600 MHz
Memory Speed Supported:   4400 MHz
Memory Speed Supported:   5100 MHz

I/O Controller
Controller Type:   Serial ATA/600
RAID Supported:   Yes
RAID Levels:   0
RAID Levels:   10
RAID Levels:   1

Video
Onboard Video:   CPU Dependent Video

Audio
Audio Channels:   7.1

Network & Communication
Bluetooth:   Yes
2.5Gigabit Ethernet:   Yes
Wireless LAN:   Yes
Wireless LAN Standard:   IEEE 802.11 a/b/g/n/ac/ax

I/O Expansions
Number of Total Expansion Slots:   4
Total Number of PCI Express Slots:   4
Number of PCI Express x1 Slots:   2
Number of PCI Express x16 Slots:   2

Interfaces/Ports
Total Number of USB Ports:   10
Number of USB 2.0 Ports:   2
Number of USB 3.2 Ports:   1
Number of USB 3.2 Gen 1 Ports:   4
Number of USB 3.2 Gen 2 Type-A Ports:   3
S/PDIF:   Yes
HDMI:   Yes
Number of Network (RJ-45) Ports:   1

Onboard Interfaces
Number of SATA Interfaces:   8
Number of M.2 Interfaces:   4
Total Number of Onboard USB Ports:   9
Number of Onboard USB 2.0 Ports:   4
Number of Onboard USB 3.2 Ports:   5

Physical Characteristics
Form Factor:   ATX
Width:   12"
Depth:   9.6"

Miscellaneous
Brand Compatibility:   AMD
Country of Origin:   China

Warranty
Limited Warranty:   3 Year

Proposition 65 Warning for California Consumers

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
